- The gun oscillating group occurs through a central arm connected totrolley that slide along pads with recirculating bearings with rails on lateral guides the movement of which is realized by a timing belt controlled by inverter.
- That trolley moves one gun-holder arm located in the middle of the spraying chamber.
- The oscillating mechanism is separated from the spraying zone, with the following advantages:
+ Absence of turbulence in the spraying zone during the oscillating
phase to obtain a perfect quality on the piece.
+ By not being in contact with the spraying zone to extend its life and
require little maintenance.
