Model: GT-GJB3213-L68-JY
Power supply: 380V 50Hz
HF input: 40KW
HF output: 30KW
HF frequency: 6.78MHz
Adjustment mode: Automatic adjustment
Cooling mode: Air cooling
Protection mode: Over current, lightning, wind pressure, door switch, etc.
Installation position: On the top of the joining machine
Worktable size: 3200mm × 1300mm
Processing thickness: 8–80mm
Vertical pressing force: 20T
Horizontal pressing force: 48T
Vertical cylinder quantity & diameter: 4 pcs × φ63mm × 250mm
Horizontal cylinder quantity & diameter: 16 pcs × φ50mm × 100mm
Motor: 4KW
Rated pressure: 16Mpa
Feeding control: Inverter
Feeding mode: Chain conveyor
Feeding speed: 25m/min
Feeding motor: 1.5KW
Output: Non-powered roller table
Glue-proof table: Coated with glue-proof layer
Pressure control: Numerical control (NC) adjustment
PLC brand: Siemens
Electrical system: Schneider and Omron
Machine size: 12000 × 2550 × 2850 mm
Machine weight: approx. 8000Kg
