LOG GANTRY SAW

LOG GANTRY SAW
Product’s name LOG GANTRY SAW
Product code GT-MJ3780X91300X30
Price Contact
Description

Product details

MODEL: GT-MJ3780X91300X30

Max. processing size: 1300 x 1300 x 3000 mm

Number of fixed clamps: 3 pcs

Clamping method: pneumatic

Flywheel diameter: 800 mm

Flywheel width: 72 mm

Saw blade size: 7180 x 80 x 1.15 mm

Saw kerf: 1.8–2 mm

Feeding speed: 0–25 m/min

Flywheel motor: 30 kW

Saw blade moving motor: 3 kW

Saw blade lifting motor: 2.6 kW

Conveyor speed: 31 m/s

Hydraulic pressure: 90 Kg/cm²

Dust outlet diameter: 102 mm × 2

Machine dimensions: 4700 x 3200 x 2300 mm

Machine weight: 3400 Kg
