✔ Automatically detects & removes wood defects
✔ Flexible cutting sizes – fully customizable
✔ Maximize wood utilization – save material costs
✔ Boost production speed & ensure accurate finishing
Technical Specifications
Model: ZHX-S200A
Working width: 20–200mm
Working thickness: 12–80mm
Max. cutting size: 120×80mm
Feeding conveyor (Option): 6300mm
Outfeed conveyor (Option): 5000mm
Outfeed with 3 pushers (Option)
Worktable width: 330mm
Min. feeding length: 400mm
Feeding speed: 80m/min
Main feeding rollers: 6 sets
Saw blade diameter: 455mm
Saw spindle speed: 3500 rpm
Saw motor: 6 sets × 5.5kW
Sawing stroke frequency: 2–4 times/sec
Lifting servo motor: 3kW
Feeding servo motor: 3kW/2kW
Outfeed motor: 0.75kW
Pressure roller lift motor: 0.18kW
Total power: 14.43kW
Roller diameter: 160mm
Air consumption: 1000nL/min
Air pressure: 0.6mpa
Dust port: Ø140mm × 2
Exhaust speed: 30m/sec
Machine weight: 1000kg
Machine size: 16000 × 1400 × 1800mm
- The modern solution to upgrade your woodworking productivity.
- Contact us now for more details & quotation!
